Segment AL-1 · Live node · Seal leak monitor & vapor detection · Hourly reporting
ALL CLEAR
VIEW PIPELINE →
Tennessee Pipeline
15 main line valves · Seal leak monitoring · Hourly reporting
ALL CLEAR
VIEW PIPELINE →
Pelham Server Room HVAC
Pelham Pump Station · Apex Cloud monitoring
📶 HVAC Node — · 📶 Duct Node —
🌡️ LIVE SERVER ROOM TEMP —
PENDING
—
COMPRESSOR LINE Δ (°F)
SYSTEM STATUS —
⚠ ACTIVE ALERTS
Compressor Start Sequence
R TSTAT—
Y TSTAT—
G TSTAT—
W TSTAT—
R BARD—
Y BARD IN—
HPC—
LPC1—
LPC2—
CC OUT—
ALR—
COMP CTR—
FAN CYC—
COND FAN—
BLOWER—
HEAT CTR—
Temperatures
—waiting for probe…
Site — Pelham AL
HUMIDITY—
FEELS LIKE—
CONDITIONS—
WIND—
Diagnostics
CONDENSER FAN—
COOLING Δ (RET−SUP)—
DEFROST—
MIN ΔT MET—
SUPPORTING READINGS
WHAT WE EMAIL YOU ABOUT
⚡ DEVICE PENDING REGISTRATION — Contact Apex Tech Systems to provision monitoring hardware for this unit
—
—
⚠ DATA SHOWN IS LAST KNOWN STATE · NODES REPORT HOURLY · AMBER = STALE OR OVERDUE
NOTICES
Compressor Start Sequence
Pelham Server Room HVAC · Real-time diagnostic · Device online
○
Reading sequence…
Live from control circuit telemetry
Temperature Trends
Pelham Server Room HVAC · Historical performance · Cycle analysis
No data yet.
Loading…
↺ restart baseline
Compressor Trend
Pelham Server Room HVAC · cooling call · contactor · line Δ · LPC/HPC/alarm — one time axis
Loading…
Compressor Discharge vs Outdoor Air
Loading…
usual middleusual rangeuncommonraredots = individual readings, last 14 days
The temperature of the hot gas leaving the compressor, against how warm it is
outside. It climbs with outdoor temperature because the system has to reject heat into hotter air
— that is normal. The shaded band is what is usual for this unit at that outdoor
temperature, measured from its own history. Above the band means the compressor is working
harder than it should for the conditions; it does not by itself say why.
Compressor Suction vs Outdoor Air · corrected to a 70°F room
Loading…
usual middleusual rangeuncommonraredots = individual readings, last 14 days
The temperature of the cold gas returning to the compressor. It tracks outdoor
temperature more loosely than discharge does, because it also follows how much heat the building is
putting into the air — so expect a wider band. Outdoor temperature here is reconstructed from
the refrigerant circuit, since the outdoor probe on this unit sits in the sun and reads about 23°F
high.
usual middleusual rangeuncommonraredots = individual readings, last 14 days
Heat rejected into the airstream, against outdoor temperature. The shaded band is the
usual range at each temperature and the line is the middle of it, both measured from
this unit. The band falls as it gets hotter because a condenser can only shed so much
heat when the outside air is nearly as warm as the coil — that is physics, not a fault.
Only a reading below the band matters; above it means it is rejecting heat better than
usual for the conditions.
Expected supply is built from outdoor air: the unit's own refrigerant readings, checked each night against the outdoor probe. Room temperature is tracked separately. Crews sometimes cool the room with other units (doors open, extra fans), so a trend is only reported when the outdoor-air view and the room-temperature view agree. Measured drifting above expected = the unit losing capacity.
The refrigerant line leaving the indoor coil. If the coil runs too cold, moisture on it can ice over and block airflow. This shows how much margin there is and which way it is heading.
coil temperature at 70° room / 70° outdoor (daily)coldest reading each day32° water freezes
Caution line is provisional until a technician measures refrigerant superheat on site; until then this panel judges margin against 32°F only.
Cooling Δ vs Outdoor Air
Loading…
usual middleusual rangeuncommonraredots = individual readings, last 14 days
How much colder the air gets as it passes through the unit, against how warm it is
outside. The shaded band is what is normal for this unit at that outdoor temperature, measured
from its own history. It slopes downward because every air conditioner cools less as it gets hotter
outside — that is physics, not a fault. A reading inside the band is ordinary; only a reading
below it is worth attention.
Supply Air vs Outdoor Air · corrected to a 70°F room
Loading…
usual middleusual rangeuncommonraredots = individual readings, last 14 days
The air leaving the vents, adjusted to what it would be with the server room at 70°F,
so a cool room does not look like a fault. It rises with outdoor temperature for the same reason the
cooling Δ falls. Only above the band is a concern: the unit is not delivering air as cold as it
usually does for these conditions. Colder than usual is shown but not flagged.
My HVAC Parts
Pelham Server Room HVAC · Component reference
These were some of the components present on the unit the day the HVAC monitor was installed — provided simply for your reference and convenience.
Component
Mfg
Model
Part #
Details
Notes
Compressor Contactor
MARS
780
61430
24VAC coil · 480VAC · FLA 30A · LRA 150A · 10 HP
Condenser fan is also fed from this contactor — connected to T2 and T3 (single-phase 480V).
Condenser Fan Contactor
MARS
780
61430
24VAC coil · 480VAC · FLA 30A · LRA 150A · 10 HP
This is actually the compressor contactor, also serving the condenser fan — may be an aftermarket field job.
Heater 1 Contactor
obsolete
Bard
—
8401-002
24VAC coil · 480VAC · FLA 25A · LRA 125A · 15 HP
Replaced by 8401-002BX.
Heater 2 Contactor
obsolete
Bard
—
8401-002
24VAC coil · 480VAC · FLA 25A · LRA 125A · 15 HP
Replaced by 8401-002BX.
Compressor Control Module
obsolete
Bard
—
8201-148
—
Direct replacement 8201-176BX.
Phase Monitor
obsolete
Bard
—
8201-126
—
Direct replacement 8201-174BX — even the replacement has limited availability.
Control Transformer
obsolete
Bard
—
8407-042
480VAC primary · 24VAC secondary · 50 VA
Direct replacement 8407-069BX.
Blower Capacitor
—
—
—
15 µF ±5%
—
Heater Limit Switch (210°F)
obsolete
Bard
—
8402-094BX
210°F heater limit switch
Direct replacement 8402-094BX.
obsolete manufacturer-discontinued at time of survey — replacement part noted where known.
Component Testing
Capacitors · measured µF from voltage & current
With the unit running, measure the AC voltage across the capacitor terminals, and clamp an ammeter on one capacitor lead to read its current. Enter the nameplate rating and your two readings, then calculate. Formula: µF = current ÷ (2π × frequency × voltage).
Battery Management
Fleet battery health · Predicted replacement · Live from telemetry
—
NODE
SITE / BATTERY
CARRIER
STATUS
PM DATE
REALISTIC
● ≤30d ● 31–90 ● >90 · ▲ high-consumption flag ·
Days fill in once nodes accumulate consumption data on battery power.
